Robotrad-s

Dough and moulding divider with dividing head and side grid

Robotrad-s

Dough and moulding divider with dividing head and side grid

Daub’s Robotrad-s is a successful hydraulic dough and moulding divider for artisan bread that benefited from a long pre-proofing time.

By using the dividing head, dough can be divided in equal and accurate weight portions. By using the side grid holder, it is possible to mould and form the dough without the use of any pressure. Moulding and forming is achieved by gently moving dough through the interchangeable grid which is available in various long, square, circular and triangle versions.

As the dough comes out in its final shape, it can be transferred straight into the oven.

When the side grid holder is placed in upper position, the Robotrad-s has all functionalities of the Robocut hydraulic dough divider.

Side grids are Teflon coated for easy cleaning and reducing the need for flour during the dividing process. When not in use, the grids can be placed on storage hooks on one or both sides of the machine. Storage hooks are able to hold a maximum of 6 grids.

All Robotrad models have a 43 x 43.5 x 12 cm bowl for up to 20 kg of dough.

Robotrad-s Pressing, dividing, forming and moulding by moving and holding joy-stick lever up and down. Standard equipped with variable pressure regulation.

Robotrad-s Automatic Pressing, dividing, forming and moulding by a single touch of joy-stick lever; one touch will start automatic work cycle of pressing, dividing forming and moulding. Including auto release of the lid at the end of the cycle, automatic end-switch and cycle time reduction. Standard equipped with variable pressure regulation.

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Pressing, dividing, moulding and forming by joy-stick or touch control panel
  • Variable hydraulic pressure regulation
  • Dividing head 6x, 10x, 12x, 20x, 24x or 40x for dough pieces from 120 to 3340 gr.
  • Automatic rising of dividing knife for easy cleaning
  • Dividing head composed of easy exchangeable food grade ertalyte dividing segments
  • High grade stainless steel dividing knife and top plate
  • Automatic motor and safety switch for extra energy efficiency and operator security
  • Grid support is closed, locked and unlocked in one fluent natural movement
  • Lightweight moulding grids are easily removed, exchanged and simply secured
    Broad range of different teflon coated interchangeable grids with various long, square, circular and triangle moulding forms
    Grid holder can be placed on left or right side

Power 1.6 kW, 3-phase, net weight 385 kg
WxDxH 82 x 66 x 108 cm

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Double dividing head 6/12x, 10/20x, 12/24x or 20/40x
  • Teflon coated stainless steel top plate
  • Storage hooks on one or both sides for up to 3 grids
  • Flour tray with cover to be placed at left, right, front-left or front-right side
  • Stainless steel working table on left or right side; completely foldable
  • Glass panel with touch controls for extra hygiene
  • Safety switches on front and removable side panels
  • Cast iron foot on wheels for extra stability
  • Special colour

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Interchangeable moulding grid
  • Lower press plate (height 5 mm – yellow)
  • Soft press pad for better separation of soft dough types (height 5 mm – blue)
  • Trolley rack for up to 8 dough bins
  • Trolley rack with wooden top plate for up to 4 dough bins
  • Trolley rack with stainless steel top plate for up to 4 dough bins
  • Dough bin with lid (20L)
  • Recommended spare part set for 5-year operation
  • Recommended spare part set for 10-year operation

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Pressing, dividing, moulding and forming by joy-stick or touch control panel
  • Variable hydraulic pressure regulation
  • Dividing head 6x, 10x, 12x, 20x, 24x or 40x for dough pieces from 120 to 3340 gr.
  • Automatic rising of dividing knife for easy cleaning
  • Dividing head composed of easy exchangeable food grade ertalyte dividing segments
  • High grade stainless steel dividing knife and top plate
  • Automatic motor and safety switch for extra energy efficiency and operator security
  • Grid support is closed, locked and unlocked in one fluent natural movement
  • Lightweight moulding grids are easily removed, exchanged and simply secured
    Broad range of different teflon coated interchangeable grids with various long, square, circular and triangle moulding forms
    Grid holder can be placed on left or right side

Power 1.6 kW, 3-phase, net weight 385 kg
WxDxH 82 x 66 x 108 cm

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Double dividing head 6/12x, 10/20x, 12/24x or 20/40x
  • Teflon coated stainless steel top plate
  • Storage hooks on one or both sides for up to 3 grids
  • Flour tray with cover to be placed at left, right, front-left or front-right side
  • Stainless steel working table on left or right side; completely foldable
  • Glass panel with touch controls for extra hygiene
  • Safety switches on front and removable side panels
  • Cast iron foot on wheels for extra stability
  • Special colour

Robotrad-s
Dough and moulding divider with dividing head and side grid

  • Interchangeable moulding grid
  • Lower press plate (height 5 mm – yellow)
  • Soft press pad for better separation of soft dough types (height 5 mm – blue)
  • Trolley rack for up to 8 dough bins
  • Trolley rack with wooden top plate for up to 4 dough bins
  • Trolley rack with stainless steel top plate for up to 4 dough bins
  • Dough bin with lid (20L)
  • Recommended spare part set for 5-year operation
  • Recommended spare part set for 10-year operation
